Item no.
CU-B05-05-C
Mini B USB cable 50cm, PREMIUM+ quality, certified USB 2.0 high speed cable (www.usb.org TID 60000532), USB A male to Mini B (5pins) male, 28AWG/1P 20AWG/2C (stronger 5V lines), double shielded (braid cover degree 80%), diameter 5mm, black
key features
- USB 2.0 cable A to Mini B
- certified cable (www.usb.org, with TID no.)
- very high quality PREMIUM+
- thicker 5V power lines: AWG20/2C
- double shielded
- data lines AWG28/1P (twisted pair)
- shielded plugs
- 30µm gold plating on contacts
- operating temperature: -20°C to +75°C
- storage temperature: -40°C to +85°C
- cable diameter about Ø 5mm
- USB 2.0 plug A male (upstream/to PC)
- small USB 2.0 Mini B plug male, 5 pins (downstream/to USB device)
- compatible USB 2.0, backward compatible USB 1.1
- for 480 Mbps (high speed), 12 Mbps (full speed) and 1.5 Mbmps (low speed)
- colour: black
- length: 0,5 meter
